Three Phase SMS/GSM Based Pump Motor Controller

SMS or GSM Remote Pump Controller is a device which can control and monitor electric motors, agriculture pump or submersible pump sets through mobile phone. This is a GSM-based pump controller to switch ON and OFF pump sets or an electric motor with a cell phone from a remote location. Download free android application. This SMS or GSM pump motor controller helps the farmer to handle agricultural pump sets easily. The farmer can set up to five schedules for automatically start and stop the pump. It also helps the farmers to save a life from snake bite in the night time, saves water, time and electricity. One SIM Card is required for its operation.

  • This GSM Pump Controller is compatible with three phase normal and submersible pump.
  • Five users can operate the pump from their cell phone.
  • Five schedules can be set to On/Off the pump automatically daily basis.
  • Over and under voltage protection.
  • Single phasing protection.
  • Dry run protection.
  • Overhead tank full detection to stop tank overflow.
  • One year warranty
  • 7 Days Replacement
  • 3,9908,850 54% Off

    Cash On Delivery (COD) Available

    Also Include

    Include internal battery backup

    300.00500.00 40% Off

    Rating & Reviews

    Android App Demo - Hindi

    Installation - Hindi

    Installation - English

    SMS or GSM Pump Controller Application Area

    Agriculture

    Industry

    Factories

    Technical Specification

    Network GSM/GPRS
    Band Quad-band: EGSM 900 / DCS 1800 and GSM 850 / PCS 1900 Mhz
    Transmitting Power Class 4 (2W) at EGSM 900 / GSM 850
    Class 1 (1W) at DCS 1800 / PCS 1900
    Supply Voltage 440 V AC, 50 Hz.
    Internal Voltage 12V DC
    Output 3 potential free relay contact
    Contact rating 20 Amp. for RL1 and RL2 relay and 7 Amp. RL3 relay
    Power Consumption 1.2 Watt
    Monthly Consumption 1 Unit
    Temperature -20 to + 70 degree Celsius
    Dimension 287mm * 158mm * 62mm.
    Weight 700 gm.

    Brief Description of SMS or GSM Pump Controller

    440V AC required to operate the controller.

    Internal battery backup (Optional) AC power status notification through SMS.

    Switch ON/OFF agriculture pump set through "MISSED CALL" or "SMS" from cell phone.

    Suitable for any Three Phase or Submersible Pump.

    Suitable for all type of Starters Panel.

    Control from 5 user's mobile phone.

    Five schedule timer for automatic pump On/Off.

    AC power status notification through SMS.

    Over and under voltage protection.

    Single phasing protection.

    Dry run protection.

    Overhead tank full detection to stop tank overflow.

    Configurable via SMS.

    Download

    Android application   Download

    User Manual of NTSMS-P106 Three Phase GSM Pump Controller   Download
