Semi-Automatic Pump Controller for 1Hp Motor
Manual on auto stop semi-automatic pump controller, water level indicator for up to 1Hp motor. The pump should be switched on manually. When the tank becomes full the controller will turn the pump off and generates an alarm.
|Supply Voltage||230 V AC, 50 Hz.|
|Internal Voltage||12V DC|
|Power Consumption||1.2 Watt|
|Monthly Consumption||1 Unit|
|Temperature||-20 to + 70 degree Celsius|
|Dimension||160mm * 100mm * 49mm.|
Brief Description of Tank Overflow Alarm
Manual start auto stop.
Gives alarm before tank overflow.
Suitable for submersible pump starter and piano switch panel
Suitable for all type of tank size and shape.
